5/8" x 4-1/2" Wedge Anchor - Galvanized

Name: 5/8" x 4-1/2" Wedge Anchor - Galvanized
Brand: Forces
SKU: FWAHDG58412CT
Price: 39.85 CAD
Availability: InStock

ForcesSKU: FWAHDG58412CT

Diameter: 5/8"

Length: 4-1/2"

Qty. Per Box: 10

Variant

Price:

$39.85 CAD

Stock:

In stock

Quantity:

Share this product

Product Details : 5/8" x 4-1/2" Wedge Anchor - Galvanized

Product Type: Wedge Anchor
Drill Size: 5/8"
Diameter: 5/8"
Length: 4-1/2"
Thread Length: 2"
Load Capacity - Wall Mounted/Concrete: 1349 kg
Load Capacity - Ceiling Mounted/Concrete: 830 kg
2000 PSI Concrete -Pull Out (lbs): 3749
2000 PSI Concrete -Shear (lbs): 6198
Important Information: As a safety factor, industry standards recommend using 25% of the ultimate load (Break Point). Ultimate load in 2000 PSI concrete.
Material(s): Galvanized

For any information about products, please contact us.

*Photos for reference purposes only.
