Product Details : Push to Connect Double Banjo 1/4" Tube x 1/8" NPT Male
-
Part No: P26.1/4.1/8
-
Product Category: Push to Connect
-
Format: Standard
-
Style: Banjo Union
-
Number Of Exits: 2
-
Type: Male Fitting
-
O-Ring: No O-Ring
-
Material(s): Polymer
-
Fluid Type: Air (no other gases or liquids)
-
Connection 1: Push to Connect 1/4"
-
Connection 2: 1/8" NPT
-
øD: 1/4"
-
R: NPT1/8"
-
øP: 14.4mm
-
A: 8mm
-
B: 15mm
-
C: 17mm
-
E: 30.2mm
-
F: 12.5mm
-
G: 4.5mm
-
H: 9/16"
-
øJ: 14mm
-
K: 20mm
-
ød: 3.2mm
-
X: 12mm
-
Y: 14mm
-
Working Pressure Range: 0-284PSI / 0 - 20Kgf-cm² (0-1960kpa)
-
Negative Pressure: -29.5 in Hg / -750mmHg (10Torr)
-
Temperature Range: 32-176°F / 0-80°C
-
Applicable Tube Material: Polyurethane and Nylon
