Description
Engineered for maximum shaft stability and severe-duty power transmission, our Type C double strand sprockets deliver dependable drive synchronization across dual-chain lines. Featuring balanced dual-side hubs, they provide extended bore contact and rigid keyway support to eliminate shaft wobble and axial deflection under heavy reversing torque. Precision-machined tooth profiles ensure uniform roller seating across both strands, distributing high tensile loads evenly to resist tooth galling and premature chain elongation. Built to handle heavy shock loading and continuous cycling, they maximize drive life across industrial conveyors, bucket elevators, and primary power trains.
• Double Strand Sprocket Type C Drawing PDF
Product Details : 80C60 Double Strand Sprocket With Stock Bore | D80C60
- Part No: D80C60
- Product Type: C (Stock Bore)
- Sprocket Type: Type C-Hub Sprocket
- Chain Strand Type: Double
- Bore: Stock Bore
- ANSI Chain Size: 80
- No. Of Teeth: 60
- Pitch: 1"
- Pitch Diameter: 19.107"
- Outside Diameter: 19.680"
- Bore Stock: 1-1/2"
- Bore Max.: 3-3/4"
- Hub Diameter: 5-3/4"
- Hub Length Thru Bore: 3-3/4"
- Material(s): Carbon Steel
- Certifications: Manufactured using the ISO 9001 quality management system.
- Avg. Weight (lbs): 93.3
For any information about products, please contact us.
*Photos for reference purposes only.
