Description
Engineered to deliver high-torque mechanical connections, our coupling chains provide rugged, flexible power transmission between adjacent shafts. Built with high-tensile double-strand rollers and precision-heat-treated side plates, each chain absorbs angular and parallel misalignment while dampening operational vibration. The matched-link design wraps securely around double-sprocket hubs, distributing rotational loads evenly to prevent tooth fatigue and shock-load damage. Equipped with an easily removable connecting pin for fast assembly and teardown, this durable chain offers dependable, low-maintenance performance across motors, speed reducers, pumps, and industrial drive assemblies.
Product Details : C5018 Chain For Chain Coupling
- Part No: CH5018
- Series: C5018
- Pitch -P (IN): 0.63"
- Roller Diameter (IN): 0.4"
- Roller Width (IN): 0.38"
- Pin Diameter (IN): 0.2"
- Plate Height (IN): 0.57"
- Plate Thickness (IN): 0.08"
- Overall Width -A (IN): 0.76"
- Overall Width -B (IN): 0.81"
- Transverse Pitch -C (IN): 0.71"
- Material(s): Carbon Steel
For any information about products, please contact us.
*Photos for reference purposes only.
