Product Details : Cast Iron Silver Caster 4" x 2" Swivel 700 lbs Roller Bearing P21 Series
-
Product Type: Medium Duty Industrial Casters
-
Series: P21 Series
-
Wheel Material: Cast Iron Silver
-
Caster Type: Swivel
-
Brake Options: No Brake
-
Mount Type: Top Plate
-
Plate Material: Zinc Finish
-
Wheel Diameter: 4"
-
Wheel Width: 2"
-
Tread / Tire Material(s): Solid Silver Cast Iron
-
Wheel Core / Rim Material(s): Solid Silver Cast Iron
-
Bearing Type: Roller Bearing
-
Load Capacity (lbs): 700 lbs
-
Total Height: 5-5/8"
-
Swivel Lead: 1-3/8"
-
Top Plate No.: 14
-
Plate Size: 4" x 4-1/2"
-
Bolt Hole Spacing: 2-5/8" x 3-5/8" to 3" x 3"
-
Bolt Hole Size: 3/8"
-
Where Used:
• Platform trucks
• Industrial carts
• Work tables
• Dollies
• Material handling
• Industrial equipment
-
Features:
• Hardened double ball raceways with Ø 5/8" kingpin
• Zinc plated finish resists rust and corrosion
• 1/2" axle and locknut
• Strong welded construction
• Multiple wheel bearing and braking options available
• Grease fitting standard on raceway and axle
• Rig leg spacing: 2-7/16"
• Hardness: 145 HB
• Temperature range: -15° to 800° F
-
Wheel Treads: Cast iron wheels offer an excellent load carrying ability and the lowest rolling resistance
-
Certified Quality Management System: ISO 9001
-
Warranty: 3 Year
