Description
Product Details : Push in to Connect Tube Splicer Reducer 5/16" to 1/4"
- Part No: P7.5/16.1/4
- Product Category: Push to Connect
- Format: Standard
- Style: Tube Splicer
- Type: Tube Fitting
- O-Ring: No O-Ring
- Material(s): Polymer
- Fluid Type: Air (no other gases or liquids)
- Connection 1: Push-In Sleeve 5/16"
- Connection 2: Push-In Sleeve 1/4"
- øD1: 5/16"
- øD2: 1/4"
- B: 39mm
- C1: 18.5mm
- C2: 17mm
- Working Pressure Range: 0-284PSI / 0 - 20Kgf-cm² (0-1960kpa)
- Negative Pressure: -29.5 in Hg / -750mmHg (10Torr)
- Temperature Range: 32-176°F / 0-80°C
- Applicable Tube Material: Polyurethane and Nylon
For any information about products, please contact us.
*Photos for reference purposes only.
